Description
Specifications
| Voltage Divider | : 10 or 12 stage with R = 510 K Ohms |
| Signal Input | : Pulse Shape Rise time – Around 100pSec (Not Measureable on Scope) Fall time – 80uSec Typical Amplitude – App. 200mV |
| Signal Output | : Polarity – Negative Pulse Shape – Rise time 100nSec, Fall time App. 80uSec Typical Amplitude – App. 1600mV Polarity – Positive Gain – 8 |
| Power Supply | : ± 15 V or ± 12 V DC |
| Power Connector | : 3 pin Amphenol female Connector |
| HV Connector | : BNC female |
| Signal Output | : BNC female |
Due to continuous R&D, specifications are likely to change without notice
